Dahua 8 Channel 32MP 1U 8PoE 2HDDs WizSense Network Video Recorder NVR5208-8P-EI

Dahua NVR5208-8P-EI 8-Channel PoE Network Video Recorder

Overview:
The Dahua NVR5208-8P-EI is a high-performance 8-channel network video recorder (NVR) designed for seamless, high-definition surveillance. Perfect for small to medium-sized businesses, retail stores, offices, or home security setups, this NVR offers robust features including PoE support, 4K recording, and AI-powered analytics. With simple installation, reliable performance, and large storage capacity, the NVR5208-8P-EI is the ideal choice for building a scalable video surveillance system.

Key Features:

8 PoE Ports: Directly power up to 8 IP cameras through PoE (Power over Ethernet), reducing the need for separate power adapters and simplifying installation.

4K Ultra HD Recording: Capture crystal-clear video at up to 8MP (4K resolution) for detailed monitoring and playback.

H.265+ Video Compression: Optimize storage with H.265+ compression technology, allowing for longer recording periods while maintaining high video quality.

Large Storage Capacity: Supports 2 SATA hard drives with a maximum storage of 16TB Each, providing ample space for video footage.

Remote Access: Monitor and manage your system remotely via PC, mobile app, or web interface. Stay in control from anywhere.

AI Features (Optional): Take advantage of AI-powered video analytics, including motion detection, facial recognition, and perimeter protection (dependent on connected cameras).

HDMI & VGA Video Output: Connect to monitors or TVs for live viewing via HDMI (up to 4K) and VGAvideo output.

User-Friendly Interface: Intuitive interface for easy configuration and real-time monitoring. Compatible with Dahua’s SmartPSS and DMSS mobile app.



Specifications:

General:

• Model: NVR5208-8P-EI

• Channels: 8 IP camera channels

• Max. Resolution: 32MP

• PoE Ports: 8 x 10/100 Mbps PoE ports 1-8 Ports support EPOE

• Video Output: 1 x HDMI, 1 x VGA

• Power Supply: 48V/2.5A, 100-240V AC

• Working Temperature: -10°C to +55°C (14°F to 131°F)

Video & Audio:

• Max. Incoming/ Outgoing Bandwidth: 384 Mbps

• Recording Resolution:32MP;24MP;16MP;12MP;8MP;5MP;4MP;1080p; 720p; D1; CIF; QCIF

• Compression Formats:
  • H.265+, H.265, H.264+, H.264

• Audio Input/Output: 1 x Audio Input, 1 x Audio Output (dependent on camera configuration)

Storage:

• Storage Type: 2 x SATA hard drives (not included)

• Max. Storage Capacity: 16TB each

• Storage Format: SATA HDD (recommended for video storage)

Network:

• Network Interface: 1 x 10/100/1000 Mbps Ethernet

• Protocol Support: TCP/IP, UDP, DHCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS

• Remote Access:
  • Web browser (IE, Firefox, Chrome)
  • Mobile app (DMSS for iOS/Android)
  • PC software (SmartPSS)

PoE Ports:

• PoE Power Output: 48V DC, 25.5W per port (max. total output: 130W)

• PoE Standard: IEEE 802.3af/at

AI Features (Optional):

• Motion Detection
• Face Detection
• Intrusion Detection
• Line Crossing Detection
• Perimeter Protection
  (AI features depend on connected cameras)

Other Features:

• HDMI Video Output: 4K (3840x2160) at 30 Hz

• VGA Video Output: 1920x1080 resolution

• USB Ports: 2 x USB 2.0 (for backup and peripheral connection)

• PTZ Control: Supported for compatible PTZ cameras

• On-Screen Display (OSD): Yes

• Software Integration: Supports DMSS mobile app and SmartPSS for easy system management

• Security: Supports HTTPS, password protection, and secure login protocols

Package Includes:

• 1 x Dahua NVR5208-8P-EI 8-Channel PoE NVR
• Power adapter
• Remote control
• User manual

Ideal For:

• Small to medium-sized businesses

• Retail stores and offices

• Residential surveillance

• Commercial properties

---

Upgrade your surveillance system with the Dahua NVR5208-8P-EI—reliable, scalable, and secure. Order today for next-level video management!
