Dahua 16 Channel Penta-brid 4K Value/5MP 1U 2HDDs WizSense Digital Video Recorder XVR5216AN-4KL-I3

Dahua XVR5216AN-4KL-I3
16-Channel Penta-brid 4K HDCVI Digital Video Recorder

Product Overview

The Dahua XVR5216AN-4KL-I3 is a robust 16-channel penta-brid video recorder designed to support high-performance surveillance systems. Offering full compatibility with HDCVI, AHD, TVI, CVBS, and IP video formats, this XVR provides the flexibility to integrate with a wide range of security cameras. With advanced AI features, real-time 4K recording, and intelligent search capabilities, the XVR5216AN-4KL-I3 is ideal for modern security applications requiring high-resolution monitoring and smart analytics.

Key Features

1. Penta-brid Compatibility
Supports HDCVI, AHD, TVI, CVBS, and IP cameras, allowing seamless integration with existing and new surveillance systems.

2. 4K Recording and Playback
Provides high-resolution 4K video for crystal-clear image quality, ensuring detailed monitoring and post-event analysis.

3. AI-Enhanced Surveillance

Face Detection: Identifies and captures facial images for efficient search and recognition.

Perimeter Protection: Reduces false alarms with intelligent motion detection, recognizing people and vehicles.

Smart Search: Quickly locates relevant footage with AI-driven search capabilities.

4.16 Channel Input and Expansion

Supports up to 16 analog channels with the option to add up to 24 IP cameras for a total of 40-channel capacity (with up to 6 MP resolution for IP cameras).

5. Advanced Compression Technology
H.265+ and H.264 compression reduces storage requirements while maintaining high image quality, enabling efficient data management.

6. Remote Monitoring
Compatible with Dahua’s mobile application (iDMSS or DMSS) and web browser access for real-time remote viewing and control.

7. Multiple Recording Modes
Flexible recording options include continuous, scheduled, motion-triggered, and AI-based recording, catering to varied surveillance needs.

8. Enhanced Storage Options
Supports up to 2 SATA HDDs, each with a capacity of up to 10 TB, ensuring ample storage for high-resolution footage.

9. HDMI and VGA Output
Provides simultaneous HDMI (4K) and VGA outputs for flexible display options.

10. Robust Build and Security
Reliable, secure design with features like dual-stream recording, password protection, and network security protocols.



Specifications

Video Input: 16 channels (BNC)

IP Channel Input: Up to 24 channels (up to 6 MP resolution)

Video Output: HDMI (4K), VGA (1080p)

Compression: H.265+/H.264

Storage: 2 SATA ports (up to 10 TB per HDD)

Audio In/Out: 1/1 channel

Network Interface: 1 RJ-45 (10/100/1000 Mbps)

USB Ports: 2 (USB 2.0, USB 3.0)

AI Features: Face Detection, Perimeter Protection, Smart Search

Applications

The Dahua XVR5216AN-4KL-I3 is perfect for a wide range of applications, including:

Commercial Buildings

Retail Stores

Warehouses

Office Complexes

Schools and Universities

Residential Properties

This high-performance DVR offers enhanced security, flexibility, and smart monitoring capabilities to ensure reliable surveillance for any environment.
